I got my funk switches and need a wiring diagram or some help on pin placement. I found two different diagrams but neither seem to be correct.
I usually am pretty good with this kind of thing but you know them Germans....



? What the hell is a "funk" switch?



Das Radio

funk=radio



Ohhhhhhhhhhhhhh...Guess that's why I'm a noob!



can u send me both of those schematics!!! i have been looking for them i plan on adding an amp n sub but can;t do it till i got them



I used the wiring schematic from the Bose guide (user manual that came with the car) to put in my amp. There is a pin layout in it.

Just be sure you have the orientation right before you splice the wires. Its easy to have the plug upside down.



i don't have the bose guide, the pin layout for the amp is 3 columns tall



So now that you've got me interested, someone explain to me what this switch is and what it is used for, so I can decide whether I should be looking to get one myself!



The switch is used in European cars as a radio kill switch I believe, more for cops who roll with the Audi's......

you can find the B7 switch here, but make sure they send you the B7. I ordered on for a B5 and they sent me a B6 instead.

http://oempl.us/
